Hose Systems to Protect Homes from Wildfires,
Confine Prescribed Fires,
and Deliver Water Over Long Distances.
IFFC, LLC Contact: steve.shoap@alum.mit.edu Twitter: @steveshoap
The ideas presented here are protected by US Patents 7,819,345, 7,942,350, 9,561,393,
and Canadian patents 2,693,158, and 2,891,833.
I hope to license the inventions to US and Canadian companies.
and Deliver Water Over Long Distances.
IFFC, LLC Contact: steve.shoap@alum.mit.edu Twitter: @steveshoap
The ideas presented here are protected by US Patents 7,819,345, 7,942,350, 9,561,393,
and Canadian patents 2,693,158, and 2,891,833.
I hope to license the inventions to US and Canadian companies.
Las ideas presentadas aquí están protegidas por las Patentes de Estados Unidos 7.819.345, 7.942.350,
La patentes canadiense 2.693.158 y 2.891.833.
Espero licenciar los inventos a compañías estadounidenses y canadienses.
Si está leyendo esto en español, utilice Google Translate para leer el resto de mi sitio web.
La patentes canadiense 2.693.158 y 2.891.833.
Espero licenciar los inventos a compañías estadounidenses y canadienses.
Si está leyendo esto en español, utilice Google Translate para leer el resto de mi sitio web.
Spray Hose Invention to Protect Homes from Wildfire
The image above is the first page of the US Patent for the Spray Hose invention.
The patent can be seen on Google Patents by clicking HERE
To see a video of a 1.5 inch hose with (only) 2 spray nozzles, click HERE
I am partnering with a Spanish company Medi_XXI_GSA
that plans to combine my hose system with their sprinkler systems in order to protect homes
from wildfire.
Their Twitter handle is @Medi_XXI_GSA and their version of the previous video can be seen HERE
from wildfire.
Their Twitter handle is @Medi_XXI_GSA and their version of the previous video can be seen HERE
The above photo shows 200 ft of a spray hose that can protect a home from wildfire embers, and also confine a prescribed fire (RxFire). There is a spray nozzle every 10 ft that sprays water onto the adjacent area.
The hose in the above photo has a diameter of 3 inches.
Further experimentation has shown that a similar hose with diameter 1.5 inches gives exactly the same spray result. A 3 inch hose is needed for very long hose lengths, however a 1.5 inch hose will be sufficient to protect most homes.
To view a VIDEO of the 200 ft hose spraying 300 gpm of water, Click HERE
The picture above shows a house that is surrounded by the spray hose (shown in blue). A pump is pumping water out of a swimming pool into the blue spray hose. The gray water spray is shown spraying vertically from the spray hose.
A preferred direction would be an angle of 45 degrees from the ground away from the house, but is too difficult to show in the picture.
The 45 degrees would help stop the fire before it reaches the hose.
The two photos below show a closeup of how the spray hose surrounding the house is constructed.
At the top of the photo below is a fire hose that has a small hole for spraying water.
Below the fire hose are two rectangular sections of hose that have been glued together.
One rectangular hose section has a smaller rectangle cut from its center.
The other rectanglular hose section has TWO HOLES that are centered in the cut rectangle area.
Below the fire hose are two rectangular sections of hose that have been glued together.
One rectangular hose section has a smaller rectangle cut from its center.
The other rectanglular hose section has TWO HOLES that are centered in the cut rectangle area.
TWO HOLES
The photo below shows the two rectangular hose sections glued to the longer fire hose section.
When water is pumped into the long fire hose, some the of the water exits the hole in the hose.
This water enters the chamber formed by the rectangular area removed from one of the rectangular
hose sections. The water in the chamber then exits from the two hole shown in the photo.
If a hose has a single hole, the water exiting will form a narrow column. The water exiting the TWO HOLES
does not form columns, but actually forms a very wide and deep spray. The wide and deep spray pattern
is very desirable for fighting a grassfire or low intensity wildfire. The spray is also useful for stopping blowing embers from reaching the house. Embers are often the reason that a house catches fire.
The photo below shows the two rectangular hose sections glued to the longer fire hose section.
When water is pumped into the long fire hose, some the of the water exits the hole in the hose.
This water enters the chamber formed by the rectangular area removed from one of the rectangular
hose sections. The water in the chamber then exits from the two hole shown in the photo.
If a hose has a single hole, the water exiting will form a narrow column. The water exiting the TWO HOLES
does not form columns, but actually forms a very wide and deep spray. The wide and deep spray pattern
is very desirable for fighting a grassfire or low intensity wildfire. The spray is also useful for stopping blowing embers from reaching the house. Embers are often the reason that a house catches fire.
The two rectangular hose sections have a very low profile, and are flexible.
This makes them useful for creating a long spray hose with such nozzles.
Their low profile allows such a hose to be deployed from a reel.
Such a hose can also be folded and deployed from a storage cavity.
The image above is a Hale fire pump that drives the hose system.
It can deliver 300 gpm at 70 psi.
The image above is a swimming pool that supplied the water to the Hale pump.
A video showing two nozzles spraying can be seen HERE.
Note that the spray from the nozzles is very uniform across the deck planks.
The nozzles are 10 feet apart. They each have a flow of 6 gpm at 45 psi.
The spray is 18 ft high.
At 70 psi the flow rate is 15 gpm and the height is 20 ft.
